This step-by-step walkthrough shows how to create a static library (.lib file) for use with C++ apps. Using a static library is a great way to reuse code. Rather than reimplementing the same routines in every app that requires the functionality, you write them one time in a static library and then reference it from the apps. Code linked from a static library becomes part of your app—you don't have to install another file to use the code.

This walkthrough covers these tasks:

How To Include Header Files In Dev C++

Oct 24, 2017 How to write your own header file in C? As we all know that files with.h extension are called header files in C. These header files generally contain function declarations which we can be used in our main C program, like for e.g. There is need to include stdio.h in our C program to use function printf in the program.

Prerequisites

An understanding of the fundamentals of the C++ language.

Create a static library project

The instructions for how to create the project vary depending on your version of Visual Studio. To see the documentation for your preferred version of Visual Studio, use the Version selector control. It's found at the top of the table of contents on this page.

To create a static library project in Visual Studio 2019

On the menu bar, choose File > New > Project to open the Create a New Project dialog box.
At the top of the dialog, set Language to C++, set Platform to Windows, and set Project type to Library.
From the filtered list of project types, select Windows Desktop Wizard, then choose Next.
In the Configure your new project page, enter MathLibrary in the Project name box to specify a name for the project. Enter StaticMath in the Solution name box. Choose the Create button to open the Windows Desktop Project dialog.
In the Windows Desktop Project dialog, under Application type, select Static Library (.lib).
Under Additional options, uncheck the Precompiled header check box if it's checked. Check the Empty project box.
Choose OK to create the project.

To create a static library project in Visual Studio 2017

On the menu bar, choose File > New > Project.
In the New Project dialog box, select Installed > Visual C++ > Windows Desktop. In the center pane, select Windows Desktop Wizard.
Specify a name for the project—for example, MathLibrary—in the Name box. Specify a name for the solution—for example, StaticMath—in the Solution Name box. Choose the OK button.
In the Windows Desktop Project dialog, under Application type, select Static Library (.lib).
Under Additional Options, uncheck the Precompiled header check box if it's checked. Check the Empty project box.
Choose OK to create the project.

To create a static library project in Visual Studio 2015

On the menu bar, choose File > New > Project.
In the New Project dialog box, select Installed > Templates > Visual C++ > Win32. In the center pane, select Win32 Console Application.
Specify a name for the project—for example, MathLibrary—in the Name box. Specify a name for the solution—for example, StaticMath—in the Solution Name box. Choose the OK button.
In the Win32 Application Wizard, choose Next.
In the Application Settings page, under Application type, select Static library. Under Additional options, uncheck the Precompiled header checkbox. Choose Finish to create the project.

Add a class to the static library

To add a class to the static library

To create a header file for a new class, right-click to open the shortcut menu for the MathLibrary project in Solution Explorer, and then choose Add > New Item.
In the Add New Item dialog box, select Visual C++ > Code. In the center pane, select Header File (.h). Specify a name for the header file—for example, MathLibrary.h—and then choose the Add button. A nearly blank header file is displayed.
Add a declaration for a class named Arithmetic to do common mathematical operations such as addition, subtraction, multiplication, and division. The code should resemble:
To create a source file for the new class, open the shortcut menu for the MathLibrary project in Solution Explorer, and then choose Add > New Item.
In the Add New Item dialog box, in the center pane, select C++ File (.cpp). Specify a name for the source file—for example, MathLibrary.cpp—and then choose the Add button. A blank source file is displayed.
Use this source file to implement the functionality for class Arithmetic. The code should resemble:
To build the static library, select Build > Build Solution on the menu bar. The build creates a static library, MathLibrary.lib, that can be used by other programs.
Note
When you build on the Visual Studio command line, you must build the program in two steps. First, run cl /c /EHsc MathLibrary.cpp to compile the code and create an object file that's named MathLibrary.obj. (The cl command invokes the compiler, Cl.exe, and the /c option specifies compile without linking. For more information, see /c (Compile Without Linking).) Second, run lib MathLibrary.obj to link the code and create the static library MathLibrary.lib. (The lib command invokes the Library Manager, Lib.exe. For more information, see LIB Reference.)

Create a C++ console app that references the static library

To create a C++ console app that references the static library in Visual Studio 2019

In Solution Explorer, right-click on the top node, Solution 'StaticMath', to open the shortcut menu. Choose Add > New Project to open the Add a New Project dialog box.
At the top of the dialog, set the Project type filter to Console.
From the filtered list of project types, choose Console App then choose Next. In the next page, enter MathClient in the Name box to specify a name for the project.
Choose the Create button to create the client project.
After you create a console app, an empty program is created for you. The name for the source file is the same as the name that you chose earlier. In the example, it's named MathClient.cpp.

To create a C++ console app that references the static library in Visual Studio 2017
